W208PP5C5FS544
Timken® W208PP5C5FS544 200 Non-Relubricatable Square Bore Deep Groove Radial Ball Bearing, 1.177 in Dia Bore, 3.1496 in Dia Outside, 1 Rows, 1.438 in W, 8130 lb Dynamic/4460 lb Static Load
- CP#:
- Item#: W208PP5
- Mfr#: W208PP5C5FS544
- UPC: 087796041257
- Designed for environments where severe contamination is present, such as agricultural tillage equipment
- Incorporates a highly effective design molded to an exterior shroud-cap
- Tri-ply seal bearings simplifies housing designs and their extra inner-ring width provides greater support on the shaft
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Tri-ply seal bearings are designed for service involving severe contamination, such as disk harrows, disk tillers and other seed preparation equipment and certain conveyor applications. Tri-ply sealed units come in two designs - one consisting of three Timken® rubber seals separated by steel spacers and retained by steel caps in the outer ring and the other, a highly effective one-piece, molded seal design. Both designs have an exterior shroud cap to protect the seals and reinforce the exceptional sealing action of the complete unit. A patented notched seal groove design, provided on selected sizes, is one of the most positive seal retention methods ever developed.
Timken®, W208PP5C5FS544, Deep Groove Radial Ball Bearing, Non-Relubricatable Square Bore, Series: 200, 1.177 in Bore, 3.1496 in OD, 1 Rows, 1.438 in Width, Double Seal Closure, 8130 lb Dynamic/4460 lb Static Load, Steel Bearing, Buna-N Seal, 500 rpm Maximum, -50 to 120 deg C, Uncoated
SPECIFICATIONS
| Series | : | 200 |
| Bearing Material | : | Steel |
| Finish | : | Uncoated |
| Load Capacity | : | 8130 lb Dynamic/4460 lb Static |
| Maximum Speed | : | 500 rpm |
| Outside Diameter | : | 3.1496 in |
| Number of Rows | : | 1 |
| Seal Material | : | Buna-N |
| Inside Diameter | : | 1.177 in |
| Measurement System | : | Imperial |
| Width | : | 1.438 in |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Fafnir_204PY3_Catalog.pdf
