TAPN17K215SM
Timken® TAPN17K215SM Pillow Block Spherical Roller Bearing Unit, 2-15/16 in Dia Bore, 9-1/2 to 11 in L Bolt Center-to-Center, 3-3/4 in Base to Bore Centerline, 12.63 in OAL x 7.32 in OAH
- CP#:
- Item#: TAPN17K215SM
- Mfr#: TAPN17K215SM
- UPC: 883450197328
- 2300 series tapered adapter sleeve for increased shaft contact
- Best shaft concentricity and highest capacity all the while having the ability to accommodate undersized housing
- Direct drop-in replacement for SAF/SN split cap housing dimensions
- Triple-lip contacting, self-purging nitrile rubber seal is excellent in moist and dirty applications, chemical and corrosion resistant
- Bearing steel
- Double row bearing
- 22217 bearing insert bore series
- Open end type
- 360 deg shaft holding
- Accommodates undersized shafting
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® solid block mounted spherical roller bearings (housed units) feature high-performance, low operating temperature Timken® double row spherical roller bearings, cast steel housings, unique locking and sealing design options to offer protection against contaminants in the harshest environments. Timken® spherical roller bearings are ideal for handling high radial loads.
Timken®, TAPN17K215SM, Pillow Block Spherical Roller Bearing Unit, 2-15/16 in Bore, 9-1/2 to 11 in Bolt Center-to-Center Length, 3-3/4 in Base to Bore Centerline, 12.63 in Overall Length, 3.47 in Overall Width, 7.32 in Overall Height, Two-Bolt Base Mounting, Cylindrical Bore, 3 in Base Width, Tapered Adapter Locking Device, Triple Lip M Seal, Non-Expansion (Fixed), 66900 lb Dynamic/71900 lb Static Load, 1400 rpm Maximum, Cast Steel, Powder Coated
SPECIFICATIONS
| Base Width | : | 3 in |
| Base to Bore Centerline | : | 3-3/4 in |
| Bolt Center-to-Center Length | : | 9-1/2 to 11 in |
| Mounting Type | : | Two-Bolt Base |
| Expansion Type | : | Non-Expansion (Fixed) |
| Locking Device | : | Tapered Adapter |
| Finish | : | Powder Coated |
| Overall Length | : | 12.63 in |
| Load Capacity | : | 66900 lb Dynamic/71900 lb Static |
| Material | : | Cast Steel |
| Maximum Speed | : | 1400 rpm |
| Overall Width | : | 3.47 in |
| Inside Diameter | : | 2-15/16 in |
| Overall Height | : | 7.32 in |
| Measurement System | : | Imperial |
| Seal Type | : | Triple Lip M |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_DVP10K111SM_Catalog.pdf
