RCJT 5/8 NT
Timken® RCJT 5/8 NT RCJT Normal Duty NT Flange Mount Ball Bearing Unit, 5/8 in Dia Bore, 3 in L Bolt Center-to-Center, 2-Bolt Flange Mount, 3-7/8 in OAL/Dia
- CP#:
- Item#: RCJT 5/8 NT
- Mfr#: RCJT 5/8 NT
- UPC: 087796152472
- This unit has the largest variety of configurations and shaft sizes and is used for the heaviest loads at the beginning of processing
- Corrosion-resistant housing that is electroless nickel-plated and has a stainless steel grease fitting
- The protective cap withstands corrosion and prevents contamination
- The corrosion-resistant insert bearing has stainless steel balls with a nylon retainer
- It also has industrial duty contact seals with stainless steel shroud-caps
- This unit has a stainless steel lock collar
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® ball bearing housed units feature a wide-inner-ring ball bearing for additional shaft support. Designed for mounting on straight shafts with a slip fit, these housed units are available in an extensive array of types and sizes to accommodate many industrial applications.
Timken®, RCJT 5/8 NT, Flange Mount Ball Bearing Unit, Normal Duty NT, Series: RCJT, 5/8 in Bore, 3 in Bolt Center-to-Center Length, 2-Bolt Flange Mounting, 3-7/8 in Overall Length/Diameter, 1-39/64 in Overall Depth, 2-1/8 in Overall Height, Eccentric Locking Device, Steel Bearing, 2150 lb Dynamic/1070 lb Static Load, 11000 rpm Maximum, -30 to 275 deg F, Nickel Plated
SPECIFICATIONS
| Bolt Center-to-Center Length | : | 3 in |
| Series | : | RCJT |
| Bearing Material | : | Steel |
| Finish | : | Nickel Plated |
| Flange Mounting Type | : | 2-Bolt |
| Locking Device | : | Eccentric |
| Load Capacity | : | 2150 lb Dynamic/1070 lb Static |
| Maximum Speed | : | 11000 rpm |
| Overall Depth | : | 1-39/64 in |
| Overall Height | : | 2-1/8 in |
| Inside Diameter | : | 5/8 in |
| Overall Length/Diameter | : | 3-7/8 in |
| Measurement System | : | Imperial |
