QVMC11V115SM
Timken® QVMC11V115SM QVMC Tapered Bore Non-Expansion Spherical Roller Bearing Cartridge Block, 1-15/16 in Dia Bore, 4.531 in Dia Outside, 3.14 in W, Steel Bearing
- CP#:
- Item#: QVMC11V115SM
- Mfr#: QVMC11V115SM
- UPC: 883450150583
- Patented V-Lock® mechanism evenly distributes force on the shaft, helping eliminate fretting corrosion
- Maximum holding power and prevention of overtightening
- Reliable mechanical withdraw
- Preset spherical inner ring radial internal clearances
- Quick installation
- Works well with high-speed applications where shaft centering is an issue
- Triple-lip contacting, self-purging nitrile rubber seal is excellent in moist and dirty applications, chemical and corrosion resistant
- Double row, heavy duty and open end
- 22211 bearing insert bore series
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® solid block mounted spherical roller bearings (housed units) feature high-performance, low operating temperature Timken® double row spherical roller bearings, cast steel housings, unique locking and sealing design options to offer protection against contaminants in the harshest environments. Timken® spherical roller bearings are ideal for handling high radial loads.
Timken®, QVMC11V115SM, Spherical Roller Bearing Cartridge Block, Tapered Bore Non-Expansion, Series: QVMC, 1-15/16 in Bore, 4.531 in OD, 3.14 in Width, 31400 lb Dynamic/31900 lb Static Load, Steel Bearing, Nitrile Rubber Seal, 2200 rpm Grease/Oil Maximum, 32 to 104 deg F, Powder Coated
SPECIFICATIONS
| Series | : | QVMC |
| Bearing Material | : | Steel |
| Finish | : | Powder Coated |
| Load Capacity | : | 31400 lb Dynamic/31900 lb Static |
| Maximum Speed | : | 2200 rpm Grease/Oil |
| Outside Diameter | : | 4.531 in |
| Seal Material | : | Nitrile Rubber |
| Inside Diameter | : | 1-15/16 in |
| Width | : | 3.14 in |
| Measurement System | : | Imperial |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_DVC13K203SM_Catalog.pdf
