QMPR15J300ST
Timken® QMPR15J300ST Pillow Block Spherical Roller Bearing Unit, 3 in Dia Bore, 8 to 9.6 in L Bolt Center-to-Center, 3.13 in Base to Bore Centerline, 10.83 in OAL x 6.47 in OAH
- CP#:
- Item#: QMPR15J300ST
- Mfr#: QMPR15J300ST
- UPC: 883450090308
- Reduced eccentric offset locking collar results in a secure shaft lock that is designed not to release from a properly prepared shaft
- Suitable for reversing applications
- Bearing steel
- Open end type
- Double row bearing
- 22215 bearing insert bore series
- Increased shaft holding power
- Reduced shaft damage under extreme shock loads
- Designed not to release in reversing applications
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® solid block mounted spherical roller bearings (housed units) feature high-performance, low operating temperature Timken® double row spherical roller bearings, cast steel housings, unique locking and sealing design options to offer protection against contaminants in the harshest environments. Timken® spherical roller bearings are ideal for handling high radial loads.
Timken®, QMPR15J300ST, Pillow Block Spherical Roller Bearing Unit, 3 in Bore, 8 to 9.6 in Bolt Center-to-Center Length, 3.13 in Base to Bore Centerline, 10.83 in Overall Length, 4.06 in Overall Width, 6.47 in Overall Height, Four-Bolt Base Mounting, Cylindrical Bore, 3.38 in Base Width, Eccentric Locking Device, Labyrinth T Seal, Non-Expansion (Fixed), 49900 lb Dynamic/54100 lb Static Load, 2400 rpm Grease/2900 rpm Oil Maximum, Cast Steel, Powder Coated
SPECIFICATIONS
| Base Width | : | 3.38 in |
| Base to Bore Centerline | : | 3.13 in |
| Bolt Center-to-Center Length | : | 8 to 9.6 in |
| Mounting Type | : | Four-Bolt Base |
| Expansion Type | : | Non-Expansion (Fixed) |
| Locking Device | : | Eccentric |
| Finish | : | Powder Coated |
| Overall Length | : | 10.83 in |
| Load Capacity | : | 49900 lb Dynamic/54100 lb Static |
| Material | : | Cast Steel |
| Maximum Speed | : | 2400 rpm Grease/2900 rpm Oil |
| Overall Width | : | 4.06 in |
| Inside Diameter | : | 3 in |
| Overall Height | : | 6.47 in |
| Measurement System | : | Imperial |
| Seal Type | : | Labyrinth T |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_DVP10K111SM_Catalog.pdf
