QMPL08J108SMNP
Timken® QMPL08J108SMNP Pillow Block Spherical Roller Bearing Unit, 1-1/2 in Dia Bore, 4.69 to 6 in L Bolt Center-to-Center, 1.88 in Base to Bore Centerline, 6.88 in OAL x 3.73 in OAH
- CP#:
- Item#: QMPL08J108SMNP
- Mfr#: QMPL08J108SMNP
- UPC: 883450500531
- Reduced eccentric offset locking collar results in a secure shaft lock that is designed not to release from a properly prepared shaft
- Suitable for reversing applications
- Triple-lip contacting, self-purging nitrile rubber seal is excellent in moist and dirty applications, chemical and corrosion resistant
- Nickel plated
- Bearing steel
- Double row bearing
- 22208 bearing insert bore series
- Open end type
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® solid block mounted spherical roller bearings (housed units) feature high-performance, low operating temperature Timken® double row spherical roller bearings, cast steel housings, unique locking and sealing design options to offer protection against contaminants in the harshest environments. Timken® spherical roller bearings are ideal for handling high radial loads.
Timken®, QMPL08J108SMNP, Pillow Block Spherical Roller Bearing Unit, 1-1/2 in Bore, 4.69 to 6 in Bolt Center-to-Center Length, 1.88 in Base to Bore Centerline, 6.88 in Overall Length, 2.88 in Overall Width, 3.73 in Overall Height, Two-Bolt Base Mounting, Cylindrical Bore, 2-1/4 in Base Width, Eccentric Locking Device, Triple Lip M Seal, Non-Expansion (Fixed), 23400 lb Dynamic/22400 lb Static Load, 2700 rpm Maximum, Cast Steel, Powder Coated
SPECIFICATIONS
| Base Width | : | 2-1/4 in |
| Base to Bore Centerline | : | 1.88 in |
| Bolt Center-to-Center Length | : | 4.69 to 6 in |
| Mounting Type | : | Two-Bolt Base |
| Expansion Type | : | Non-Expansion (Fixed) |
| Locking Device | : | Eccentric |
| Finish | : | Powder Coated |
| Overall Length | : | 6.88 in |
| Load Capacity | : | 23400 lb Dynamic/22400 lb Static |
| Material | : | Cast Steel |
| Maximum Speed | : | 2700 rpm |
| Overall Width | : | 2.88 in |
| Inside Diameter | : | 1-1/2 in |
| Overall Height | : | 3.73 in |
| Measurement System | : | Imperial |
| Seal Type | : | Triple Lip M |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_DVP10K111SM_Catalog.pdf
