Timken®
QMMH15J215ST
Timken® QMMH15J215ST QMMH Cylindrical Bore Non-Expansion Hanger Roller Bearing Unit, 2-15/16 in Dia Bore, 6.38 in Dia Outside, 3.62 in W, Steel Bearing, Eccentric Locking
- Item#: QMMH15J215ST
- Mfr#: QMMH15J215ST
- UPC: 883450410199
- Reduced eccentric offset locking collar results in a secure shaft lock that is designed not to release from a properly prepared shaft
- Suitable for reversing applications
- 22215 bearing insert bore series
- Double row, heavy duty, open end and single collar
- Cast steel housing
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® solid block mounted spherical roller bearings (housed units) feature high-performance, low operating temperature Timken® double row spherical roller bearings, cast steel housings, unique locking and sealing design options to offer protection against contaminants in the harshest environments. Timken® spherical roller bearings are ideal for handling high radial loads.
Timken®, QMMH15J215ST, Hanger Roller Bearing Unit, Cylindrical Bore Non-Expansion, Series: QMMH, 2-15/16 in Bore, 6.38 in OD, 3.62 in Width, 49900 lb Dynamic/54100 lb Static Load, Eccentric Locking, Steel Bearing, PTFE Seal, 3200 rpm Maximum, 32 to 104 deg F, Powder Coated
SPECIFICATIONS
| Type | : | Cylindrical Bore Non-Expansion |
| Series | : | QMMH |
| Bearing Material | : | Steel |
| Finish | : | Powder Coated |
| Load Capacity | : | 49900 lb Dynamic/54100 lb Static |
| Locking Type | : | Eccentric |
| Maximum Speed | : | 3200 rpm |
| Outside Diameter | : | 6.38 in |
| Seal Material | : | PTFE |
| Temperature Rating | : | 32 to 104 deg F |
| Inside Diameter | : | 2-15/16 in |
| Mounted | : | Yes |
| Width | : | 3.62 in |
| Measurement System | : | Imperial |
