QMMC22J408SM
Timken® QMMC22J408SM QMMC Cylindrical Bore Non-Expansion Spherical Roller Bearing Cartridge Block, 4-1/2 in Dia Bore, 8-3/4 in Dia Outside, 5.53 in W, Steel Bearing
- CP#:
- Item#: QMMC22J408SM-P01
- Mfr#: QMMC22J408SM
- UPC: 883450168106
- Reduced eccentric offset locking collar results in a secure shaft lock that is designed not to release from a properly prepared shaft
- Suitable for reversing applications
- Triple-lip contacting, self-purging nitrile rubber seal is excellent in moist and dirty applications, chemical and corrosion resistant
- Double row, heavy duty and open end
- Cast steel housing
- 22222 bearing insert bore series
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® solid block mounted spherical roller bearings (housed units) feature high-performance, low operating temperature Timken® double row spherical roller bearings, cast steel housings, unique locking and sealing design options to offer protection against contaminants in the harshest environments. Timken® spherical roller bearings are ideal for handling high radial loads.
Timken®, QMMC22J408SM, Spherical Roller Bearing Cartridge Block, Cylindrical Bore Non-Expansion, Series: QMMC, 4-1/2 in Bore, 8-3/4 in OD, 5.53 in Width, 125000 lb Dynamic/147000 lb Static Load, Steel Bearing, Nitrile Rubber Seal, 900 rpm Grease/Oil Maximum, 32 to 104 deg F, Powder Coated
SPECIFICATIONS
| Series | : | QMMC |
| Bearing Material | : | Steel |
| Finish | : | Powder Coated |
| Load Capacity | : | 125000 lb Dynamic/147000 lb Static |
| Maximum Speed | : | 900 rpm Grease/Oil |
| Outside Diameter | : | 8-3/4 in |
| Seal Material | : | Nitrile Rubber |
| Width | : | 5.53 in |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_DVC13K203SM_Catalog.pdf
