NP831379-902A2
Timken® NP831379-902A2 Type SRNB-1(3) Tapered Roller Bearing, 10 in Dia Bore, 14-1/8 in OD, 4 Rows, 10-5/8 in W, 720000 lb Dynamic Load
- CP#:
- Item#: NP831379-902A2-P01
- Mfr#: NP831379-902A2
- UPC: 053893024745
- Four single cups for optimum load sharing
- Effective sealing at cup outer diameter (OD) to seal contaminants away from bearing OD and chock bore
- Improved surface finishes to enhance lubrication performance
- Inboard and outboard cone face slots that reduce cone face wear
- Spiral bore grooves with blended radii to eliminate roll neck damage
- Case-carburized components to improve toughness and increase fatigue life
- Patented seal designs with improved contact geometry for enhanced sealing
- Enhanced roller profiling for even load distribution, which reduces edge stress
- No central cone or cup spacers to minimize number of components to be handled
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® Tapered Roller Bearing, Type SRNB-1(3), 10 in Bore Dia, 14-1/8 in Outside Dia, 4 Rows, 10-5/8 in Width, 720000 lb Dynamic, Steel Bearing, Stamped Steel Cage, -65 to 250 deg F
SPECIFICATIONS
| Bearing Material | : | Steel |
| Load Capacity | : | 720000 lb Dynamic |
| Outside Diameter | : | 14-1/8 in |
| Number of Rows | : | 4 |
| Width | : | 10-5/8 in |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_190TTSX940OA617_Catalog.pdf
