E-4BF-TRB-50MM
Timken® E-4BF-TRB-50MM Heavy Duty Non-Expansion Round Bore Type E Tapered Roller Bearing Unit, 50 mm Dia Bore, 111.125 mm L Bolt Center-to-Center, 4-Bolt Square Flange Mount, 142.875 mm OAL/Dia
- CP#:
- Item#: E-4BF-TRB-50MM
- Mfr#: E-4BF-TRB-50MM
- UPC: 053893544014
- Industry leading high performance triple-barrier seals result in improved grease retention and are more effective at preventing water and mud/slurry ingress
- Rotating collar acts as an initial flinger and provides an additional barrier
- Electric deposition coatings on housings and collars provide superior corrosion resistance
- Set screws with nylon patch greatly reduce set screw back out, even in the most severe applications
- High performance Timken® bearings provide the highest rating and bearing life
- Double row bearing
- Cast iron housing
- Triple barrier seal type
- Do not operate at bearing temperatures above 121 deg C
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® Type E mounted tapered roller bearings (housed units) feature industry leading premium tapered roller bearings, high performance triple-barrier seals, e-coated housings and locking collars. Timken® tapered roller bearings have the capacity to manage both radial and axial loads and are engineered to provide the greatest durability in the most compact space.
Timken®, E-4BF-TRB-50MM, Tapered Roller Bearing Unit, Heavy Duty Non-Expansion Round Bore Type E, 50 mm Bore, 111.125 mm Bolt Center-to-Center Length, 4-Bolt Square Flange Mounting, 142.875 mm Overall Length/Diameter, 88.9 mm Overall Depth, 142.875 mm Overall Height, Double Set Screw Collar Locking Device, Steel Bearing, 10300 lb Dynamic/43000 lb Static Load, 3050 rpm Maximum, -54 to 250 deg F, E-Coated
SPECIFICATIONS
| Bolt Center-to-Center Length | : | 111.125 mm |
| Bearing Material | : | Steel |
| Finish | : | E-Coated |
| Flange Mounting Type | : | 4-Bolt Square |
| Locking Device | : | Double Set Screw Collar |
| Load Capacity | : | 10300 lb Dynamic/43000 lb Static |
| Maximum Speed | : | 3050 rpm |
| Overall Depth | : | 88.9 mm |
| Overall Height | : | 142.875 mm |
| Inside Diameter | : | 50 mm |
| Overall Length/Diameter | : | 142.875 mm |
| Measurement System | : | Metric |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_E_PF_TRB_1_3_4_Catalog.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_E_4BF_TRB_45MM_Specification_Sheet.pdf
