6305-NR
Timken® 6305-NR 6300 Medium Standard Straight Bore ISO Deep Groove Radial Ball Bearing, 25 mm Dia Bore, 62 mm Dia Outside, 1 Rows, 17 mm W, 4631 lb Dynamic64214329714/2517.86 lb Static Load
- CP#:
- Item#: 6305-NR
- Mfr#: 6305-NR
- UPC: 013992162335
- Super finished raceways
- Quiet operation
- ISO standard interchangeable dimensions
- Electric motor quality (EMQ)
- Snap ring provides an adequate shoulder without sacrificing capacity
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® supplies a full range of product in the world's most popular design series. Timken® metric deep groove ball bearings deliver reliable performance in a wide range of applications and conditions.
Timken®, 6305-NR, ISO Deep Groove Radial Ball Bearing, Medium Standard Straight Bore, Series: 6300, 25 mm Bore, 62 mm OD, 1 Rows, 17 mm Width, Open Closure, 4631 lb Dynamic64214329714/2517.86 lb Static Load, Cold Rolled Steel Cage, 12000 rpm Grease/17000 rpm Oil Maximum, -50 to 120 deg C
SPECIFICATIONS
| Bearing Type | : | Unmounted Ball Bearing |
| Series | : | 6300 |
| Bearing Material | : | Steel |
| Load Capacity | : | 4631 lb Dynamic64214329714/2517.86 lb Static |
| Maximum Speed | : | 12000 rpm Grease/17000 rpm Oil |
| Outside Diameter | : | 62 mm |
| Number of Rows | : | 1 |
| Overall Width | : | 17 mm |
| Inside Diameter | : | 25 mm |
| Mounted | : | Unmounted |
| Measurement System | : | Metric |
| Width | : | 17 mm |
