6202-NR
Timken® 6202-NR 6200 Light Straight Bore ISO Deep Groove Radial Ball Bearing, 15 mm Dia Bore, 35 mm Dia Outside, 1 Rows, 11 mm W, 1708.548 lb Dynamic/831.793 lb Static Load
- CP#:
- Item#: 6202-NR
- Mfr#: 6202-NR
- UPC: 013992162113
- Super finished raceways
- Quiet operation
- ISO standard interchangeable dimensions
- Electric motor quality (EMQ)
- Snap ring provides an adequate shoulder without sacrificing capacity
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® supplies a full range of product in the world's most popular design series. Timken® metric deep groove ball bearings deliver reliable performance in a wide range of applications and conditions.
Timken®, 6202-NR, ISO Deep Groove Radial Ball Bearing, Light Straight Bore, Series: 6200, 15 mm Bore, 35 mm OD, 1 Rows, 11 mm Width, Open Closure, 1708.548 lb Dynamic/831.793 lb Static Load, Cold Rolled Steel Cage, 28000 rpm Grease/19000 rpm Oil Maximum, -50 to 120 deg C
SPECIFICATIONS
| Bearing Type | : | Unmounted Ball Bearing |
| Series | : | 6200 |
| Bearing Material | : | Steel |
| Load Capacity | : | 1708.548 lb Dynamic/831.793 lb Static |
| Maximum Speed | : | 28000 rpm Grease/19000 rpm Oil |
| Outside Diameter | : | 35 mm |
| Number of Rows | : | 1 |
| Overall Width | : | 11 mm |
| Inside Diameter | : | 15 mm |
| Mounted | : | Unmounted |
| Measurement System | : | Metric |
| Width | : | 11 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_16012_C3_Catalog.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_6202_NR_Specification_Sheet.pdf
