39590-30000
Timken® 39590-30000 39500 Type TSF Tapered Roller Bearing, 2-5/8 in Dia Bore, 4.6523 in Dia Outside, 1 Rows, 1-3/16 in W, 37500 lb Dynamic/50300 lb Static Load
- CP#:
- Item#: 39590-3
- Mfr#: 39590-30000
- UPC: 053893280868
- Internal geometry provides increased stiffness and exceptional runout
- Radial runout high point marked for accurate installation
- Timken® outer (cup) and inner (cone) rings should be used in combination
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
The TSF type is a variation on the basic single row bearing. TSF bearings have a flanged outer ring to facilitate axial location and accurately aligned seats in a through bored housing.
Timken®, 39590-30000, Tapered Roller Bearing, Type TSF, Series: 39500, 2-5/8 in Bore, 4.6523 in OD, 1 Rows, 1-3/16 in Width, 37500 lb Dynamic/50300 lb Static Load, Steel Bearing, -65 to 250 deg F
SPECIFICATIONS
| Series | : | 39500 |
| Bearing Material | : | Steel |
| Load Capacity | : | 37500 lb Dynamic/50300 lb Static |
| Outside Diameter | : | 4.6523 in |
| Number of Rows | : | 1 |
| Inside Diameter | : | 2-5/8 in |
| Measurement System | : | Imperial |
| Width | : | 1-3/16 in |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_14125A_90082_Catalog.pdf
