Thomson®
8107-448-017
Thomson® 8107-448-017 MAR Legacy Type A Non-Preloaded Round Ball Nut, 3/4 in Dia Screw, 0.2 in, 1 Circuits, 1.312 in OD
- Item#: 8107-448-017
- Mfr#: 8107-448-017
- 300 deg F operating temperature
- Nut only, screw sold separately
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Thomson® Ball Nut, Type A Non-Preloaded Round, Series: MAR Legacy, 3/4 in Screw Diameter, 1.312 in OD, 1 Circuits, 1.89 in Nut Length, 1.173-18 UNS-2A Thread, Right Hand Thread, 0.2 in Thread Lead, 950 lb Dynamic/7750 lb Static Load, For Use With: MAR Legacy Precision Rolled Ball Screw, Steel, Black Oxide
SPECIFICATIONS
| Finish | : | Black Oxide |
| Load Capacity | : | 950 lb Dynamic/7750 lb Static |
| Material | : | Steel |
| Nut Length | : | 1.89 in |
| Series | : | MAR Legacy |
| Suitable For Use With | : | MAR Legacy Precision Rolled Ball Screw |
| Thread Direction | : | Right Hand |
| Thread Size | : | 1.173-18 UNS-2A |
| Type | : | Type A Non-Preloaded Round |
| Screw Diameter | : | 3/4 in |
| Thread Lead | : | 0.2 in |
| Number of Circuits | : | 1 |
| Outside Diameter | : | 1.312 in |
