Spherco® CTFD4Y
Spherco®

Spherco® CTFD4Y

loading

CTFD4Y

Spherco® CTFD4Y CTFD Female Spherical Plain Rod End, 1/4 in Dia Bore, 3/4 in OD, 3/8 in W, 1060 lb Load, Carbon Steel

  • Item#: CTFD 4YRBC
  • Mfr#: CTFD4Y
  • UPC: 637400181888
    • 8 deg misalignment angle
    • Maintenance free virtually no radial clearance
    • Dimensional stability
    • Right handed thread handedness
    • Commercial performance
    • Self-lubricating thermoplastic race
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Spherco® offers a wide range of rod end types and sizes. Spherco®'s product range includes rod ends with brass race inserts in standard, precision and high capacity designs, high strength two-piece designs and self-lubricating rod end with engineered thermoplastic races or Teflon® liners with a wide range of optional features such as lubrication fittings, left hand threads, and keyway slots.

Spherco® Spherical Plain Rod End, Female, Series: CTFD, 1/4 in Bore Dia, 3/4 in Outside Dia, 3/8 in Width, UNF-3B Thread, 1/4-28 Thread, 1.312 in Center Line Length, 1060 lb, 125 deg F, Carbon Steel, 1.687 in H

SPECIFICATIONS

Center Line Length      :      1.312 in
Series      :      CTFD
Dimensions      :      1.687 in H
Load Capacity      :      1060 lb
Material      :      Carbon Steel
Outside Diameter      :      3/4 in
Thread Size      :      1/4-28
Thread Type      :      UNF-3B
Width      :      3/8 in

DOCUMENTS

  • pdf
    Catalog
    https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/429/Spherco_AR10_Catalog.pdf
