SNR® NJ2313EG15
SNR®
Email Print

NJ2313EG15

SNR® NJ2313EG15 Cylindrical Roller Bearing, 65 mm Dia Bore, 140 mm OD, 1 Row, 48 mm W, 287 kN Load

  • Item#: NJ2313EG15
  • Mfr#: NJ2313EG15
    • Withstand radial loads
    • Withstand moderate axial loads if the position of the shoulders on the rings allows them
    • Accept high speeds of rotation
    • High strength machined brass rivetless cage with square holes
    • ISO class 0 tolerance rating
    • Round bore
    • 247 kN dynamic/287 kN static
    • Without oil hole
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Cylindrical roller bearings offer excellent resistance to instantaneous overloads and shocks. They simplify assembly thanks to their detachable elements and allow, for certain types, axial displacement or low axial load, for other types.

SNR® Cylindrical Roller Bearing, Series: NJ23, 65 mm Bore Dia, 140 mm Outside Dia, 1 Row, 48 mm W, Open Closure, 287 kN, Hardened Alloy Steel Bearing, Machined Brass Cage, 6000 rpm Maximum, -20 to 120 deg C

SPECIFICATIONS

Series      :      NJ23
Bearing Material      :      Hardened Alloy Steel
Load Capacity      :      287 kN
Maximum Speed      :      6000 rpm
Outside Diameter      :      140 mm
Number of Rows      :      1
Width      :      48 mm
