N220EG15
SNR® N220EG15 N2 Series Cylindrical Roller Bearing, 100 mm Dia Bore, 180 mm OD, 1 Row, 34 mm W, 308 kN Load
- CP#:
- Item#: N220EG15
- Mfr#: N220EG15
- Withstand radial loads
- Withstand moderate axial loads if the position of the shoulders on the rings allows them
- Accept high speeds of rotation
- High strength machined brass rivetless cage with square holes
- ISO class 0 tolerance rating
- Round bore
- Without oil hole
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Cylindrical roller bearings offer excellent resistance to instantaneous overloads and shocks. They simplify assembly thanks to their detachable elements and allow, for certain types, axial displacement or low axial load, for other types.
SNR® Cylindrical Roller Bearing, Series: N2 Series, 100 mm Bore Dia, 180 mm Outside Dia, 1 Row, 34 mm W, Open Closure, 308 kN, Hardened Alloy Steel Bearing, Machined Brass Cage, 4500 rpm Maximum, -20 to 120 deg C
SPECIFICATIONS
| Series | : | N2 Series |
| Bearing Material | : | Hardened Alloy Steel |
| Load Capacity | : | 308 kN |
| Maximum Speed | : | 4500 rpm |
| Outside Diameter | : | 180 mm |
| Number of Rows | : | 1 |
| Width | : | 34 mm |
DOCUMENTS
-
VIDEO LINK
https://youtu.be/4rXPAd9xD3w
