MLE7011CVDUJ84S
SNR® MLE7011CVDUJ84S 70 Series Round Bore Standard Angular Contact Ball Bearing, 55 mm Dia Bore, 90 mm OD, 2 Rows, 36 mm W, 15 deg, 23300 N Load
- CP#:
- Item#: MLE7011CVDUJ84S
- Mfr#: MLE7011CVDUJ84S
- Can be used alone as a double bearing
- Withstand axial loads in both directions
- Non-contact seal
- Medium preload
- Stratified cage
- High performance bearings
- High speed range
- 23300 N dynamic/21700 N static
- Steel ball
- ISO class 4 tolerance rating
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
SNR® Angular Contact Ball Bearing, Round Bore Standard, Series: 70 Series, 55 mm Bore, 90 mm OD, 2 Rows, 36 mm Width, 15 deg Contact Angle, Double Seal Closure, 23300 N Load, High Carbon Chrome Steel Bearing, Nitrile Rubber Seal, Phenolic Cage, 22000 rpm Grease/30500 rpm Oil Maximum, -40 to 120 deg C
SPECIFICATIONS
| Series | : | 70 Series |
| Bearing Material | : | High Carbon Chrome Steel |
| Contact Angle | : | 15 deg |
| Load Capacity | : | 23300 N |
| Maximum Speed | : | 22000 rpm Grease/30500 rpm Oil |
| Outside Diameter | : | 90 mm |
| Number of Rows | : | 2 |
| Seal Material | : | Nitrile Rubber |
| Width | : | 36 mm |
