ML7005CVDUJ74S
SNR® ML7005CVDUJ74S 70 Series Round Bore Standard Angular Contact Ball Bearing, 25 mm Dia Bore, 47 mm OD, 2 Rows, 24 mm W, 15 deg, 7450 N Load
- CP#:
- Item#: ML7005CVDUJ74S
- Mfr#: ML7005CVDUJ74S
- Can be used alone as a double bearing
- Withstand axial loads in both directions
- Light preload
- Stratified cage
- High performance bearings
- High speed range
- 7450 N dynamic/4500 N static
- Steel ball
- ISO class 4 tolerance rating
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
SNR® Angular Contact Ball Bearing, Round Bore Standard, Series: 70 Series, 25 mm Bore Dia, 47 mm Outside Dia, 2 Rows, 24 mm W, 15 deg Contact, Open Closure, 7450 N, High Carbon Chrome Steel Bearing, Phenolic Cage, 44500 rpm Grease/59000 rpm Oil Maximum, -40 to 120 deg C
SPECIFICATIONS
| Series | : | 70 Series |
| Bearing Material | : | High Carbon Chrome Steel |
| Contact Angle | : | 15 deg |
| Load Capacity | : | 7450 N |
| Maximum Speed | : | 44500 rpm Grease/59000 rpm Oil |
| Outside Diameter | : | 47 mm |
| Number of Rows | : | 2 |
| Width | : | 24 mm |
