CH7005CVDUJ74
SNR® CH7005CVDUJ74 70 Series Round Bore Standard Angular Contact Ball Bearing, 25 mm Dia Bore, 47 mm OD, 2 Rows, 24 mm W, 15 deg, 13000 N Load
- CP#:
- Item#: CH7005CVDUJ74
- Mfr#: CH7005CVDUJ74
- Can be used alone as a double bearing
- Withstand axial loads in both directions
- Light preload
- Stratified cage
- High performance bearings
- 13000 N dynamic/8600 N static
- Hybrid ceramic ball
- ISO class 4 tolerance rating
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
SNR® Angular Contact Ball Bearing, Round Bore Standard, Series: 70 Series, 25 mm Bore Dia, 47 mm Outside Dia, 2 Rows, 24 mm W, 15 deg Contact, Open Closure, 13000 N, High Carbon Chrome Steel Bearing, Phenolic Cage, 30000 rpm Grease/47000 rpm Oil Maximum, -40 to 120 deg C
SPECIFICATIONS
| Series | : | 70 Series |
| Bearing Material | : | High Carbon Chrome Steel |
| Contact Angle | : | 15 deg |
| Load Capacity | : | 13000 N |
| Maximum Speed | : | 30000 rpm Grease/47000 rpm Oil |
| Outside Diameter | : | 47 mm |
| Number of Rows | : | 2 |
| Width | : | 24 mm |
