- SMC® KQ2L04-00A
KQ2L04-00A
SMC® KQ2L04-00A KQ2 Union One-Touch Fittings, 4 x 4 mm Nominal, Push-In End Style, C3604/PBT/PP/Stainless Steel/NBR
- CP#:
- Item#: KQ2L04-00A
- Mfr#: KQ2L04-00A
- Accepts FEP, PFA, nylon, soft nylon, and polyurethane tubes
- Operating pressure range, -100kPa to 1MPa
- Release collar allows easy removal of tubing without causing damage to the tube
- This product is not intended for use in potable water systems
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
SMC®, KQ2L04-00A, One-Touch Fittings, Union, Series: KQ2, Fitting/Connector: Elbow, 4 x 4 mm Nominal, Push-In End Style, -100 kPa to 1 MPa Pressure, -5 to 60 deg C, C3604/PBT/PP/Stainless Steel/NBR, White/Light Gray, 25.5 mm L Dimensions. For certificates of compliance, please contact your local Purvis representative.
SPECIFICATIONS
| Color | : | White/Light Gray |
| Dimensions | : | 25.5 mm L |
| Pressure Rating | : | -100 kPa to 1 MPa |
| Series | : | KQ2 |
| Temperature Rating | : | -5 to 60 deg C |
| Fitting/Connector Type | : | Elbow |
| Type | : | Union |
| Nominal Size | : | 4 x 4 mm |
| End Style | : | Push-In |
| Material | : | C3604/PBT/PP/Stainless Steel/NBR |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/SMC_KQ2T11_35AS_Catalog.pdf
