GE 6 E
SKF® GE 6 E Radial Spherical Plain Bearing, 6 mm Dia Bore, 14 mm OD, 6 mm W, 17 kN Load
- CP#:
- Item#: GE 6 E
- Mfr#: GE 6 E
- 3.5 kN dynamic/17 kN static load
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
A characteristic feature of SKF steel/steel radial spherical plain bearings is the outer ring, which is intentionally fractured so that it can be sprung apart to enable the inner ring to be inserted. The bearings are therefore non-separable and easy to handle. The bearings are manganese phosphate and the sliding contact surface is then treated with a running-in lubricant. This reduces friction and wear during the running-in period. To facilitate lubrication, all bearings, with the exception of some small sizes, have an annular groove and two lubrication holes in both the inner and outer rings. Metric bearings with an outside diameter 150 mm also have the SKF multigroove system in the outer ring sliding contact surface as standard. Upon request, SKF can also supply smaller metric and inch size bearings with the multigroove system. With the multi-groove system, SKF solved the problem of lubricant starvation in steel/steel bearings. Lubricant starvation is a common cause of premature bearing failure in applications where minor alignment movements are made under heavy, constant direction loads. The multi-groove system improves lubricant distribution in the heavily loaded zone to extend bearing service life and/or maintenance intervals.
SKF® Radial Spherical Plain Bearing, Series: GE Series, 6 mm Bore, 14 mm OD, 6 mm Width, Open Closure, 17 kN Load, Steel Bearing, -50 to 200 deg C, Molybdenum
SPECIFICATIONS
| Series | : | GE Series |
| Bearing Material | : | Steel |
| Finish | : | Molybdenum |
| Load Capacity | : | 17 kN |
| Outside Diameter | : | 14 mm |
| Width | : | 6 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/129/SKF_GE6E_Catalog.pdf
