7312 BECCM
SKF® 7312 BECCM 7300 Medium Precision Angular Contact Ball Bearing, 2.3622 in Dia Bore, 5.1181 in OD, 1 Row, 1.2205 in W, 40 deg, 23380 lbf Dynamic/17198 lbf Static Load
- CP#:
- Item#: 7312 BECCM
- Mfr#: 7312 BECCM
- High load carrying capacity
- Good running properties
- Easy mounting of universally matchable bearings
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
SKF® single row angular contact ball bearings can accommodate axial loads in one direction only. This type of bearing is typically adjusted against a second bearing. Their bearing rings have an upper and a lower shoulder and are non-separable.
SKF® Angular Contact Ball Bearing, Precision, Series: 7300 Medium, 2.3622 in Bore Dia, 5.1181 in Outside Dia, 1 Row, 1.2205 in W, 40 deg Contact, Open Closure, 23380 lbf Dynamic/17198 lbf Static, Steel Bearing, Brass/Bronze Cage, 4500 rpm Reference/8500 rpm Limiting Maximum, 300 deg F
SPECIFICATIONS
| Series | : | 7300 Medium |
| Bearing Material | : | Steel |
| Contact Angle | : | 40 deg |
| Load Capacity | : | 23380 lbf Dynamic/17198 lbf Static |
| Maximum Speed | : | 4500 rpm Reference/8500 rpm Limiting |
| Outside Diameter | : | 5.1181 in |
| Number of Rows | : | 1 |
| Width | : | 1.2205 in |
DOCUMENTS
-
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/408/SKF_7312_BECCM_Specification_Sheet.pdf -
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/509/SKF_7203_BECBM_Catalog.pdf
