6315 M/C3VL0241
SKF® INSOCOAT® 6315 M/C3VL0241 6300 Series Cylindrical Bore Deep Groove Ball Bearing, 75 mm Dia Bore, 160 mm OD, 1 Row, 37 mm W, 119 kN Dynamic/76.5 kN Static Load
- CP#:
- Item#: 6315 M/C3VL0241
- Mfr#: 6315 M/C3VL0241
- Low friction and running temperatures, low noise and vibration
- High running speeds
- High quality and performance capabilities for your application
- Accommodate radial loads and axial loads in both directions
- Increased reliability and provide long bearing and lubricant service life
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Deep Groove Ball Bearings are the most widely used bearing type and are particularly versatile. They have low friction and are optimized for low noise and low vibration which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount and require less maintenance than other bearing types. The SKF® bearing catalogue lists a large range of designs, variants and sizes of deep groove ball bearings. Beyond our catalogue offering, the SKF® Explorer deep groove ball bearings are customizable to offer advantages for applications with specific performance needs.
SKF® INSOCOAT® Deep Groove Ball Bearing, Cylindrical Bore, Series: 6300 Series, 75 mm Bore Dia, 160 mm Outside Dia, 1 Row, 37 mm Width, Open Closure, 119 kN Dynamic/76.5 kN Static, Steel Bearing, Machined Brass Cage, 8000 rpm Limiting/9000 rpm Reference Maximum, Ceramic Coated
SPECIFICATIONS
| Series | : | 6300 Series |
| Bearing Material | : | Steel |
| Finish | : | Ceramic Coated |
| Load Capacity | : | 119 kN Dynamic/76.5 kN Static |
| Maximum Speed | : | 8000 rpm Limiting/9000 rpm Reference |
| Outside Diameter | : | 160 mm |
| Number of Rows | : | 1 |
| Width | : | 37 mm |
DOCUMENTS
-
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/1033/SKF_6315MC3VL0241_Specification_Sheet.pdf -
Warranty Information https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/1034/SKF_210N_Warranty.pdf -
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/1035/SKF_6300_Catalog.pdf
