32028 X
SKF® 32028 X Radial Tapered Roller Bearing, 140 mm Dia Bore, 210 mm OD, 1 Row, 45 mm W, 404 kN Dynamic/585 kN Static Load
- CP#:
- Item#: 32028 X
- Mfr#: 32028 X
- Long service life
- Increased dynamic load ratings by up to 23%
- Reduced early failure
- Better performance by less friction torque, noise and vibration, increased speed and running accuracy
- Optimum combination of material and heat treatment
- Customizable for specific requirements like high speeds, heavy loads, contaminated environment, high temperature and vibratory conditions
- X-boundary dimensions not in accordance with ISO dimension series
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
SKF® Tapered Roller Bearing, Radial, Series: 320, 140 mm Bore Dia, 210 mm Outside Dia, 1 Row, 45 mm W, Open Closure, 404 kN Dynamic/585 kN Static, Steel Bearing, Steel Cage, 2800 rpm Maximum, 250 deg F, Uncoated
SPECIFICATIONS
| Series | : | 320 |
| Bearing Material | : | Steel |
| Finish | : | Uncoated |
| Load Capacity | : | 404 kN Dynamic/585 kN Static |
| Maximum Speed | : | 2800 rpm |
| Outside Diameter | : | 210 mm |
| Number of Rows | : | 1 |
| Width | : | 45 mm |
DOCUMENTS
-
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/510/SKF_32028_X_Specification_Sheet.pdf -
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/566/SKF_25520_Q_Catalog.pdf
