- RBC® B539DDFS428
B539DDFS428
RBC® B539DDFS428 B500DD Torque Tube Standard Airframe Bearing, Ball Bearing, 3/4 in Dia Bore, 1-3/16 in OD, 0.281 in W, 3750 lb Load
- CP#:
- Item#: B539DDFS428
- Mfr#: B539DDFS428
- UPC: 637400551094
- Extra light duty single row torque tube ball bearing
- Made of bearing quality chromium-alloy, high carbon steel
- Exposed surfaces except bore and seals are cadmium plated
- Shipped with preservative oil
- Prelubricated for life
- This bearing is not intended for use in any aerospace application
- Reinforced Teflon® shield
- Aeroshell 33® type 1 grease
- 3750 lb dynamic/3750 lb static
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
RBC® Airframe Bearing, Torque Tube Standard, Series: B500DD, Ball Bearing, 3/4 in Bore Dia, 1 Row, 1-3/16 in Outside Dia, 0.281 in W, 3750 lb, 52100 Steel Bearing, PTFE Seal, -65 to 250 deg F, Cadmium
SPECIFICATIONS
| Bearing Type | : | Ball |
| Series | : | B500DD |
| Bearing Material | : | 52100 Steel |
| Finish | : | Cadmium |
| Load Capacity | : | 3750 lb |
| Number of Rows | : | 1 |
| Outside Diameter | : | 1-3/16 in |
| Seal Material | : | PTFE |
| Width | : | 0.281 in |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/448/RBC_10NBC1620YZP_Catalog.pdf
