TS2-6208L1CC3P5
NTN TS2-6208L1CC3P5 62 Series Round Bore Precision Deep Groove Ball Bearing, 40 mm Dia Bore, 80 mm OD, 1 Row, 18 mm W, 29100 N Load
- CP#:
- Item#: TS2-6208L1CC3P5
- Mfr#: TS2-6208L1CC3P5
- UPC: 4547359595840
- Clean, vacuum degassed, high carbon chromium steel that undergoes a proprietary heat treatment to reduce crack sensitivity
- High power density that allows a smaller bearing to support higher loads
- Low weight and compact designs
- ISO class 5 precision rating
- Machined cage
- C3 radial clearance greater than normal
- 29100 N dynamic/17800 N static
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Deep groove, or single row radial, ball bearings are the most widely used bearings. They utilize an uninterrupted raceway that makes them optimal for radial loads .This design permits precision tolerance, even at high-speed operation. NTN ball bearings use standard cages of pressed steel, as well as machined, brass cages for high-speed applications. NTN also offers bearings with locating snap rings.
NTN Precision Deep Groove Ball Bearing, Round Bore, Series: 62 Series, 40 mm Bore Dia, 80 mm Outside Dia, 1 Row, 18 mm W, Open Closure, 29100 N, High Carbon Chrome Steel Bearing, Brass Cage, 8700 rpm Grease/10000 rpm Oil Maximum, -40 to 160 deg C
SPECIFICATIONS
| Series | : | 62 Series |
| Bearing Material | : | High Carbon Chrome Steel |
| Load Capacity | : | 29100 N |
| Maximum Speed | : | 8700 rpm Grease/10000 rpm Oil |
| Outside Diameter | : | 80 mm |
| Number of Rows | : | 1 |
| Width | : | 18 mm |
