NUKR62XH
NTN NUKR62XH Cylindrical OD Cam Follower, 62 mm Dia x 30.5 mm W Roller, 24 mm Dia x 49.5 mm L Stud, Through Hardened Steel Roller
- CP#:
- Item#: NUKR62XH
- Mfr#: NUKR62XH
- UPC: 4547359133943
- Hexagonal socket
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
This is a track roller complete with stud instead of inner ring, which is designed to operate with its outer ring rolling on the track. These NTN stud type track rollers are applied to eccentric roller, guide roller, rocker arm roller and more. similarly to the roller followers. One end of the stud is threaded and the hexagonal nut is used to be mounted easily.
NTN Cam Follower, Cylindrical OD, Series: NUKR, 62 mm Roller Dia, 30.5 mm Roller Width, 24 mm Stud Dia, 49.5 mm Stud Length, M24 x 1.5, 25 mm Thread Length, 56500 N Dynamic/72500 N Static, 2900 rpm Grease Maximum, -40 to 120 deg C, Standard Stud, Shielded Closure, Hex, Through Hardened Steel Roller
SPECIFICATIONS
| Series | : | NUKR |
| Head Type | : | Hex |
| Load Capacity | : | 56500 N Dynamic/72500 N Static |
| Maximum Speed | : | 2900 rpm Grease |
| Roller Diameter | : | 62 mm |
| Roller Material | : | Through Hardened Steel |
| Roller Width | : | 30.5 mm |
| Stud Diameter | : | 24 mm |
| Stud Length | : | 49.5 mm |
| Stud Type | : | Standard |
| Thread Length | : | 25 mm |
| Thread Size | : | M24 x 1.5 |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/428/NTN_CR8_Catalog.pdf
