KRV35LL
NTN KRV35LL Spherical OD Cam Follower, 35 mm Dia x 19.5 mm W Roller, 16 mm Dia x 32.5 mm L Stud, Through Hardened Steel Roller
- CP#:
- Item#: KRV35LL
- Mfr#: KRV35LL
- UPC: 4547359089929
- Synthetic rubber seal
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
This is a track roller complete with stud instead of inner ring, which is designed to operate with its outer ring rolling on the track. These NTN stud type track rollers are applied to eccentric roller, guide roller, rocker arm roller and more. similarly to the roller followers. One end of the stud is threaded and the hexagonal nut is used to be mounted easily.
NTN Cam Follower, Spherical OD, Series: KRV, 35 mm Roller Diameter, 19.5 mm Roller Width, 16 mm Stud Diameter, 32.5 mm Stud Length, M16 x 1.5 Thread, 17 mm Thread Length, 17600 N Dynamic/34000 N Static Load, 5500 rpm Grease/7000 rpm Oil Maximum, -40 to 120 deg C, Standard Stud, Double Seal Closure, Slotted Head, Through Hardened Steel Roller
SPECIFICATIONS
| Series | : | KRV |
| Head Type | : | Slotted |
| Load Capacity | : | 17600 N Dynamic/34000 N Static |
| Maximum Speed | : | 5500 rpm Grease/7000 rpm Oil |
| Roller Diameter | : | 35 mm |
| Roller Material | : | Through Hardened Steel |
| Roller Width | : | 19.5 mm |
| Stud Diameter | : | 16 mm |
| Stud Length | : | 32.5 mm |
| Stud Type | : | Standard |
| Thread Length | : | 17 mm |
| Thread Size | : | M16 x 1.5 |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/428/NTN_CR8_Catalog.pdf
