FL605ZZ
NTN FL605ZZ Micro Round Bore Miniature Extra Small Radial Ball Bearing With Flanged Outer Ring, 5 mm Dia Bore, 14 mm OD, 1 Rows, 5 mm W, 39000 N Load
- CP#:
- Item#: FL605ZZ
- Mfr#: FL605ZZ
- UPC: 4547359473438
- The sealed V-slot around the inner ring creates an air and grease pocket which increases the labyrinth effect
- This is a non-contact, low-friction torque type bearing assembly, which can be used effectively for general protection
- Steel shield
- Normal clearance
- ISO class 0 precision rating
- 39000 N dynamic/114 N static
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Single Row Radial Ball Bearings are the most widely used bearings and utilize an uninterrupted raceway, which makes these bearings suitable for radial loads, or a combination of thrust and radial loads. This design permits precision tolerances even at high speed operation. The cage in this bearing is pressed steel. For high speed bearings, machined brass cages are available. Bearings with locating snap rings are also available.
NTN Radial Ball Bearing, Round Bore Miniature Extra Small, Series: Micro, 5 mm Bore, 14 mm OD, 1 Rows, 5 mm Width, 16 mm Diameter Flange, Double Shield Closure, 39000 N Load, High Carbon Chrome Steel Bearing, Pressed Steel Cage, 39000 rpm Grease Maximum, -40 to 120 deg C
SPECIFICATIONS
| Series | : | Micro |
| Bearing Material | : | High Carbon Chrome Steel |
| Flange Diameter | : | 16 mm |
| Load Capacity | : | 39000 N |
| Maximum Speed | : | 39000 rpm Grease |
| Outside Diameter | : | 14 mm |
| Number of Rows | : | 1 |
| Width | : | 5 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/428/NTN_3201_Catalog.pdf
