A-UEL206-102D1
NTN A-UEL206-102D1 Ultra Class UEL2 Round Bore Light Duty Ball Insert Bearing, 28.575 mm Dia Bore, 62 mm OD, 48.4 mm W, 19500 N Load
- CP#:
- Item#: A-UEL206-102
- Mfr#: A-UEL206-102D1
- Contact seal
- Relubricatable
- Steel ball
- Spherical OD
- CN radial clearance
- Lube on non-locking mechanism side
- 19500 N dynamic/11300 N static
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
NTN Ball Insert Bearing, Round Bore Light Duty, Series: Ultra Class UEL2, 28.575 mm Bore, 62 mm OD, 48.4 mm Width, Double Seal Closure, 19500 N Load, Hardened Steel Bearing, Nitrile Rubber Seal, 4900 rpm Grease Maximum, -40 to 120 deg C
SPECIFICATIONS
| Series | : | Ultra Class UEL2 |
| Bearing Material | : | Hardened Steel |
| Closure Type | : | Double Seal |
| Load Capacity | : | 19500 N |
| Maximum Speed | : | 4900 rpm Grease |
| Outside Diameter | : | 62 mm |
| Seal Material | : | Nitrile Rubber |
| Width | : | 48.4 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/428/NTN_3201_Catalog.pdf
