NTN 6311ZC3
NTN
Email Print

6311ZC3

NTN 6311ZC3 63 Series Round Bore Standard Medium Deep Groove Radial Ball Bearing, 55 mm Dia Bore, 120 mm OD, 1 Rows, 29 mm W, 71500 N Load

  • Item#: 6311ZC3
  • Mfr#: 6311ZC3
  • UPC: 4547359396317
    • The sealed V-slot around the inner ring creates an air and grease pocket which increases the labyrinth effect
    • This is a non-contact, low-friction torque type bearing assembly, which can be used effectively for general protection
    • ISO class 0 precision rating
    • Single shielded seal
    • C3 radial internal clearance greater than normal
    • 71500 N dynamic/45000 N static
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Deep groove ball bearings are very widely used. A deep groove is formed on each inner and outer ring of the bearing enabling them to sustain radial and axial loads in either direction as well as well as the complex loads which result from the combination of these forces. Deep groove ball bearings are suitable for high speed applications.

NTN Deep Groove Radial Ball Bearing, Round Bore Standard Medium, Series: 63 Series, 55 mm Bore, 120 mm OD, 1 Rows, 29 mm Width, Single Shield Closure, 71500 N Load, High Carbon Chrome Steel Bearing, Pressed Steel Cage, 5800 rpm Grease/6800 rpm Oil Maximum, -40 to 120 deg C

SPECIFICATIONS

Series      :      63 Series
Bearing Material      :      High Carbon Chrome Steel
Load Capacity      :      71500 N
Maximum Speed      :      5800 rpm Grease/6800 rpm Oil
Outside Diameter      :      120 mm
Number of Rows      :      1
Width      :      29 mm

DOCUMENTS

  • pdf
    Catalog     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/428/NTN_3201_Catalog.pdf
