6206LB
NTN 6206LB Round Bore Deep Groove Radial Ball Bearing, 30 mm Dia Bore, 62 mm OD, 1 Row, 16 mm W, 21.6 kN Dynamic/11.3 kN Static Load
- CP#:
- Item#: 6206LB
- Mfr#: 6206LB
- UPC: 4547359358605
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
NTN Deep Groove Radial Ball Bearing, Round Bore, 30 mm Bore Dia, 62 mm Outside Dia, 1 Row, 16 mm Width, Non-Contact Single Sealed Closure, 21.6 kN Dynamic/11.3 kN Static, High Carbon Steel Bearing, Nitrile Rubber Seal, Pressed Steel Cage, 11000 rpm Grease/13000 rpm Oil Maximum, -40 to 120 deg C, Polished Chrome
SPECIFICATIONS
| Bearing Material | : | High Carbon Steel |
| Finish | : | Polished Chrome |
| Load Capacity | : | 21.6 kN Dynamic/11.3 kN Static |
| Maximum Speed | : | 11000 rpm Grease/13000 rpm Oil |
| Outside Diameter | : | 62 mm |
| Number of Rows | : | 1 |
| Seal Material | : | Nitrile Rubber |
| Width | : | 16 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/10000/NTN_61805_Catalog.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/10000/NTN_6206LB_Specification_Sheet.pdf -
VIDEO LINK
https://youtu.be/b6svVy1lYOA
