6205LBC3
NTN 6205LBC3 62 Series Round Bore Standard Small Deep Groove Radial Ball Bearing, 25 mm Dia Bore, 52 mm OD, 1 Row, 15 mm W, 14000 N Load
- CP#:
- Item#: 6205LBC3
- Mfr#: 6205LBC3
- Both sides of the seal edge have a circular concaved surface which creates several narrow wide gaps along the V-shaped groove of the inner rings sealed surface
- The unique design ensures a perfect labyrinth effect
- This non-contact, low friction bearing assembly requires very little torque and is highly resistant to dust build-up
- ISO class 0 precision rating
- Single sealed non-contact nitrile rubber seal
- C3 radial internal clearance greater than normal
- 14000 N dynamic/7850 N static
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Deep groove ball bearings are very widely used. A deep groove is formed on each inner and outer ring of the bearing enabling them to sustain radial and axial loads in either direction as well as well as the complex loads which result from the combination of these forces. Deep groove ball bearings are suitable for high speed applications.
NTN Deep Groove Radial Ball Bearing, Round Bore Standard Small, Series: 62 Series, 25 mm Bore Dia, 52 mm Outside Dia, 1 Row, 15 mm W, Single Sealed Closure, 14000 N, High Carbon Chrome Steel Bearing, Nitrile Rubber Seal, Pressed Steel Cage, 13000 rpm Grease/15000 rpm Oil Maximum, -40 to 120 deg C
SPECIFICATIONS
| Series | : | 62 Series |
| Bearing Material | : | High Carbon Chrome Steel |
| Load Capacity | : | 14000 N |
| Maximum Speed | : | 13000 rpm Grease/15000 rpm Oil |
| Outside Diameter | : | 52 mm |
| Number of Rows | : | 1 |
| Seal Material | : | Nitrile Rubber |
| Width | : | 15 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/428/NTN_3201_Catalog.pdf
