5205C2
NTN 5205C2 52 Series Round Bore Angular Contact Ball Bearing, 25 mm Dia Bore, 52 mm OD, 2 Rows, 20.6 mm W, 25 deg, 21300 N Load
- CP#:
- Item#: 5205C2/5K
- Mfr#: 5205C2
- Without filling slot
- C2 radial clearance less than normal
- ISO class 0 precision rating
- 21300 N dynamic/14700 N static
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Double Row Angular Contact Ball Bearings have an inner and outer ring with a double raceway. The two rows are so related that the contact angle is similar to a pair of back-to-back single row bearings. The 5200 and 5300 series offer continuous races and can carry thrust loads in either direction. Since the 3200 and 3300 series have filling slots, it is necessary to mount them with the thrust load acting against the unnotched face of the rings.
NTN Angular Contact Ball Bearing, Round Bore, Series: 52 Series, 25 mm Bore Dia, 52 mm Outside Dia, 2 Rows, 20.6 mm W, 25 deg Contact, Open Closure, 21300 N, High Carbon Chrome Steel Bearing, Pressed Steel Cage, 8500 rpm Grease/11000 rpm Oil Maximum, -40 to 120 deg C
SPECIFICATIONS
| Series | : | 52 Series |
| Bearing Material | : | High Carbon Chrome Steel |
| Contact Angle | : | 25 deg |
| Load Capacity | : | 21300 N |
| Maximum Speed | : | 8500 rpm Grease/11000 rpm Oil |
| Outside Diameter | : | 52 mm |
| Number of Rows | : | 2 |
| Width | : | 20.6 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/428/NTN_3201_Catalog.pdf
