1AS08-1D1

NTN 1AS08-1D1 Heavy Duty Square Bore Type 1 Farm Implement Bearing, Disc Bearing, 1.03 in Dia Bore, 3.1496 in OD, 1.437 in W, 6550 lbf Dynamic/4000 lbf Static Load

  • Item#: 1AS08-1D1
  • Mfr#: 1AS08-1D1
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

NTN Farm Implement Bearing, Heavy Duty Square Bore Type 1, Disc Bearing, 1.03 in Bore Dia, 1 Row, 3.1496 in Outside Dia, 1.437 in Width, 6550 lbf Dynamic/4000 lbf Static, Through Hardened Steel Bearing, Nitrile Rubber Seal, -40 to 250 deg F

SPECIFICATIONS

Product Type      :      Heavy Duty Square Bore Type 1
Bearing Type      :      Disc
Bearing Material      :      Through Hardened Steel
Load Capacity      :      6550 lbf Dynamic/4000 lbf Static
Number of Rows      :      1
Outside Diameter      :      3.1496 in
Seal Material      :      Nitrile Rubber
Bore Diameter      :      1.03 in
Temperature Rating      :      -40 to 250 deg F
Duty Type      :      Heavy
Width      :      1.437 in
Mounted      :      Unspecified
Measurement System      :      Imperial

DOCUMENTS

  • pdf
    Specification Sheet
    https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/10000/NTN_1AS08_1D1_Specification_Sheet.pdf
