NOSHOK 25-310-2-1-10-2-20-3-2
NOSHOK

NOSHOK 25-310-2-1-10-2-20-3-2

loading
NOSHOK
Email Print

25-310-2-1-10-2-20-3-2

300 Series Vapor Actuated Remote Dial Indicating Thermometer

  • Item#: 25-310-2-1-10-2-20-3-2-P01
  • Mfr#: 25-310-2-1-10-2-20-3-2
    • 2-1/2"
    • 100 to 350 deg-F/deg-C Armored Copper Capillary
    • 20 ft
    • 1/2" National Pipe Thread (NPT) Union Copper Bulb
    • 4-1/2" x 3/8" Vapor Thermometer
    • -40 Degree Service Fill and Chrome Front Flange
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Indicates media temperature using a temperature-actuated liquid in the sensing element and a highly accurate, high-quality pressure gauge. As the media temperature increases, the capillary fill fluid vaporizes, increasing pressure in the Bourdon tube to activate the movement and pointer for proper indication. Available in brass, stainless steel, or phenolic cases. Dry or liquid-filled. Bottom, back, or lower back connected. The dial scale graduations are non-linear, providing the highest degree of accuracy and readability in the upper half of the scale.

SPECIFICATIONS

Type      :      Remote Dial Indicating Thermometer
Max Operating Temperature (deg F)      :      350 deg-F
Min Operating Temperature (deg F)      :      100 deg-F
