1607DCTNTG18
Nice® 1607DCTNTG18 1600® Non-Fill Slot Precision Deep Groove Ball Bearing, 7/16 in Dia Bore, 0.9063 in OD, 1 Rows, 5/16 in W, 300 lb Load
- CP#:
- Item#: 1607DCTN
- Mfr#: 1607DCTNTG18
- UPC: 637400291389
- Precision ground on all surfaces and ball grooves for smooth rotation and easy installation
- Pregreased with metered Shell Alvania #2 grease
- Double sealed to keep grease in and contaminants out
- Standard design for maximum application versatility
- 698 lb dynamic/300 lb static
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Precision ground 1600® Series bearings are specially designed to provide a line of low cost yet high quality bearings for adaptation to a majority of precision bearing applications. They are made in easy to use inch dimensions and are recommended for medium loads and for maximum speeds in the range of 5000 rpm. The 1600® Series bearings are precision ground on all surfaces with exceptional care given to the ball grooves. Careful heat treatment provides a uniform and exact degree of hardness for maximum life. A ball retainer, or separator, is used to increase the range of allowable speeds by reducing ball-to-ball contact friction.
Nice® Precision Deep Groove Ball Bearing, Non-Fill Slot, Series: 1600®, 7/16 in Bore, 0.9063 in OD, 1 Rows, 5/16 in Width, Double Seal Closure, 300 lb Load, 52100 Steel Bearing, Nylon Cage, 5000 rpm Maximum, -40 to 284 deg F, Chrome Steel
SPECIFICATIONS
| Series | : | 1600® |
| Bearing Material | : | 52100 Steel |
| Finish | : | Chrome Steel |
| Load Capacity | : | 300 lb |
| Maximum Speed | : | 5000 rpm |
| Outside Diameter | : | 0.9063 in |
| Number of Rows | : | 1 |
| Width | : | 5/16 in |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/458/Nice_40014VBF53_Catalog.pdf
