6204C3
NACHI 6204C3 Deep Groove Ball Bearing, 20 mm Dia Bore, 47 mm OD, 1 Row, 14 mm W, 12800 N Dynamic/6600 N Static Load
- CP#:
- Item#: 6204C3
- Mfr#: 6204C3
- Excellent high speed capability
- Good radial load capacity
- Good axial load capacity in both directions
- Low torque requirements during startup and operation
- Low noise
- Little/no maintenance required
- Longer life - adopted NACHI original seal design to prevent contamination and grease leakage, contains special grease for wider temperature ranges and longer life
- Smooth and quiet operation - the precision level of our bearing components has been enhanced to ensure smooth and quiet operation
- Internal clearance
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Single-row deep groove ball bearings are the most common bearing type in the world due to their versatility and performance. These bearings are available in a variety of seal, shield and snap-ring arrangements. Bearings with seals or shields are standardized and already contain the proper amount of grease. Open bearings will require lubrication. These bearings can sustain radial and/or axial loads and because of their simple design, this bearing type can be produced to provide both high-running accuracy and high-speed operation.
NACHI Deep Groove Ball Bearing, Series: 6200, 20 mm Bore, 47 mm OD, 1 Row, 14 mm Width, Open Closure, 12800 N Dynamic/6600 N Static Load, Steel Bearing, Stamped Steel Cage, 11000 rpm Grease/18000 rpm Oil Maximum, 250 deg F
SPECIFICATIONS
| Series | : | 6200 |
| Bearing Material | : | Steel |
| Load Capacity | : | 12800 N Dynamic/6600 N Static |
| Maximum Speed | : | 11000 rpm Grease/18000 rpm Oil |
| Outside Diameter | : | 47 mm |
| Number of Rows | : | 1 |
| Width | : | 14 mm |
