NACHI 51211
NACHI
Email Print

51211

NACHI 51211 51200 Thrust Ball Bearing, 55 mm Dia Bore, 90 mm OD, 25 mm W, 69500 N Dynamic/159000 N Static Load

  • Item#: 51211
  • Mfr#: 51211
    • Thrust ball bearings are designed to handle axial loads only
    • Thrust ball bearings consist of ball, retainer, both shaft and housing washers which contain grooves for the balls and can be subject to axial load only
    • The bearings with spherical housing washer can prevent static misalignment
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Thrust Ball Bearings are made as single-direction and double-direction bearings. Single-direction Thrust Ball Bearings can sustain an axial load in only one direction, whereas Double-direction Thrust Ball Bearings can sustain bi-directional thrust load. Both types of Thrust Ball Bearings cannot sustain a radial load.

NACHI Thrust Ball Bearing, Series: 51200, 55 mm Bore, 90 mm OD, 25 mm Width, Flat Back Face, Single Thrust Direction, 69500 N Dynamic/159000 N Static Load, 2100 rpm Grease/3100 rpm Oil Maximum

SPECIFICATIONS

Series      :      51200
Face Type      :      Flat Back
Load Capacity      :      69500 N Dynamic/159000 N Static
Maximum Speed      :      2100 rpm Grease/3100 rpm Oil
Outside Diameter      :      90 mm
Thrust Direction      :      Single
Width      :      25 mm

DOCUMENTS

  • pdf
    Specification Sheet     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/1078/NACHI_51101_Specification_Sheet.pdf
