XA0007
Morse® Raider® Plus XA0007 Single Reduction Standard Worm Gear Reducer, Universal Shaft-In Input, Right Hand Output, 0.125 hp, 50:1 Gear Ratio, 35 rpm Maximum Output, 121 in-lb Output Torque Rating
- CP#:
- Item#: 362979
- Mfr#: XA0007
- UPC: 662288335672
- Rugged cast iron housing provides maximum strength and dependability
- High lead angle worm is case hardened, ground and polished
- Large, single row ball bearings on input shaft to absorb radial and thrust loads at higher input speeds
- Tapered roller bearings are used on output shaft
- Forged bronze worm gears provide optimum balance of strength and wear
- Modular worm gear design provides over 10 million configurations from stock components
- Double sealing capability on input and output shafts
- Dimensionally interchangeable with major industry competitors
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Raider® Plus worm gear reducers represent the most flexible worm gear product in the power transmission solutions portfolio. With a large variety of add-on accessories, the Raider® Plus line of worm gear reducers is a problem solver. Four unit styles form the basis of this vast product offering. These are the universal style (U style, shaft input) with an output shaft and the C-face style (Q style, input quill) with an output shaft. Both the U and Q styles are also available with hollow outputs. The Raider® Plus worm gear reducer is designed as an industry interchange. It is dimensionally interchangeable with the major industry competitors.
Morse® Raider® Plus Worm Gear Reducer, Single Reduction Standard, 50:1 Gear Ratio, 0.125 hp, Universal Shaft-In Input, Right Hand Output, 0.375 in Dia x 1.23 in L Input, 1/2 in Dia x 1-1/4 in L Output, 35 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 121 in-lb Output, 1 in Centre Distance, Polyglycol Oil Lubrication, Direct/Universal Mount, Cast Iron, 4.71 in L x 4.4 in W x 3.63 in H
