Morse®
Email Print

323897

Morse® 323897 Inverted Tooth HV Chain, 10 ft OAL, 1/2 in Pitch, Carbon Steel

  • Item#: HV406 10FT
  • Mfr#: 323897
  • UPC: 662288459682
    • Designed with a pin and rocker joint, to reduce friction and provide pitch elongation for smooth sprocket engagement
    • Provides smooth, quiet and cost-efficient operation
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Morse® HV chain is ideal for applications where heavy loads (50 to 6000 hp) are to be transmitted at moderate to high speeds. It is also ideal where compact design is important. HV features a pin and rocker joint which reduces friction and provides pitch elongation through its rolling action. This results in a reduction of chordal action and a significant increase in horsepower capacity.

Morse® HV Chain, Inverted Tooth, 1/2 in Pitch, 1.651 in Pin Length, 0.57 in Plate Height, 2 Strands, 15000 lb Tensile Strength, 10 ft Overall Length, Carbon Steel

SPECIFICATIONS

Number of Strands      :      2
Overall Length      :      10 ft
Pitch      :      1/2 in
Material      :      Carbon Steel
Plate Height      :      0.57 in
Tensile Strength      :      15000 lb
Pin Length      :      1.651 in
Type      :      Inverted Tooth

DOCUMENTS

  • pdf
    Catalog     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Morse_330139_Catalog.pdf
  • pdf
    Manual     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Rollway_32012RS_Manual.pdf
