- Morse® 2657054
2657054
Morse® 2657054 KK® Series Mechanical CAM Clutch, 17 mm Dia Bore, 40 mm OD, 43 N-m Torque, 3500 rpm Inner Race/1900 rpm Outer Race Max
- CP#:
- Item#: KK17
- Mfr#: 2657054
- UPC: 662288927358
- Self-contained ball bearing and cam clutch
- Designed with same dimensions as standard metric light series ball bearing
- Furnished filled with grease to increase wear life
- The clutches are supplied with a protective coating of oil and must be lubricated before putting into service
- Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
- This general bearing clutch can be utilized with both oil and grease lubrication
- KK Clutch is available in several configurations with different sealing options and inner and outer keyway options
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
The KK® series clutch incorporates a compact cam clutch with built-in bearing support. This unique construction combines a cam clutch with a 6200 series metric ball bearing for use in several applications. These range from exercise equipment to industrial machinery. This general purpose clutch is intended for backstopping, indexing and overrunning applications. It can also be utilized with both oil and grease lubrication.
Morse® Mechanical CAM Clutch, Series: KK® Series, 17 mm Bore, 40 mm OD, 43 N-m Torque, 3500 rpm Inner Race/1900 rpm Outer Race Maximum, 12 mm W Dimensions
SPECIFICATIONS
| Dimensions | : | 12 mm W |
| Series | : | KK® Series |
| Bore Diameter | : | 17 mm |
| Outside Diameter | : | 40 mm |
| Torque Rating | : | 43 N-m |
| Maximum Speed | : | 3500 rpm Inner Race/1900 rpm Outer Race |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Morse_1296342_Catalog.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Morse_2363307_Specification_Sheet.pdf -
Manual https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Morse_2657013_Manual.pdf
