TT70BS 2

Martin TT70BS 2 Finished Bore Torque Limiter Clutch, 2 to 2-7/16 in Dia Bore, 7 in OD, 8000 in-lb Torque, 3-7/8 in OAL

  • Item#: TT70BS 2
  • Mfr#: TT70BS 2
  • UPC: 697950078120
    • Torque limiter clutch gives machinery permanent protection against overloads during starting, reversing or driving by slipping at any desired load
    • Simple in design, compact, efficient and built for long life
    • Provides low cost torque limiting service for a wide variety of applications
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Starting shock from electric motors is a major cause of maintenance of moving parts. Torque-limiter clutches provide a cushion by slipping until the torque drops to a pre-set level. They can be set to reduce shock loads on motors and driven equipment during reversing or inching. They provide mechanical protection against breakage due to sudden overload by slipping when the pre-set torque limit is reached. Martin can provide many tooth counts that are not listed by quickly altering stock sprockets.

Martin Torque Limiter Clutch, Finished Bore, 2 to 2-7/16 in Bore Dia, 7 in Outside Dia, 3-7/8 in Overall Length, 8000 in-lb, Steel

SPECIFICATIONS

Material      :      Steel
Type      :      Finished Bore
Bore Diameter      :      2 to 2-7/16 in
Outside Diameter      :      7 in
Torque Rating      :      8000 in-lb
Overall Length      :      3-7/8 in

DOCUMENTS

  • pdf
    Catalog     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Martin_TT25NA_Catalog.pdf
