E60R52

Martin E60R52 Type 25 Triple Strand Solid Bushed Roller Chain Sprocket, 1-1/8 to 3-3/4 in Dia Bore, 12.849 in OD, #60 Chain, 52 Teeth, 3/4 in Pitch, Steel

  • Item#: E60R52
  • Mfr#: E60R52
  • UPC: 697950218922
    • Interchangeable with other manufacturer's split-taper bushings
    • Precise machining and processes ensure consistent finish and high quality
    • Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
    • Bores are concentric to pitch line, minimizing run out
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Martin split taper sprocket is another style of bushed sprocket. The split taper bushing, when installed, offers a wide range of bore sizes.

Martin Roller Chain Sprocket, Type 25 Triple Strand Solid Bushed, 1-1/8 to 3-3/4 in Bore, 12.849 in OD, #60 Chain, 52 Teeth, 3/4 in Pitch, 12.4216 in Pitch Diameter, 3/4 in Keyway, 2.238 in Length Through Bore, MST® R1 Bushing, Steel

SPECIFICATIONS

Bushing Type      :      MST® R1
Bore Diameter      :      1-1/8 to 3-3/4 in
Outside Diameter      :      12.849 in
Chain Size      :      #60
Number of Teeth      :      52
Pitch      :      3/4 in
Material      :      Steel
Keyway Size      :      3/4 in
Type      :      Type 25 Triple Strand Solid Bushed
Pitch Diameter      :      12.4216 in
Length Through Bore      :      2.238 in
