E35B13H
Martin E35B13H Type B Triple Strand Solid Reboreable Roller Chain Sprocket With Hardened Teeth, 1/2 to 11/16 in Dia Bore, 1.746 in OD, #35 Chain, 13 Teeth, 3/8 in Pitch, Steel
- CP#:
- Item#: E35B13H
- Mfr#: E35B13H
- UPC: 697950003153
- Manufactured of high carbon steel
- Precise machining and processes ensure consistent finish and high quality
- Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Martin triple strand solid construction sprockets have proper spacing between chain rows. The sprockets are manufactured from high carbon steel. Martin does not stack "A" plates on multiples, but instead Martin machines teeth after the chain rows are already in place. These plain bore sprockets can easily be bored to a metric or standard size to fit your application. Keyways, setscrews and harden teeth are quick alterations that can be made.
Martin Roller Chain Sprocket, Type B Triple Strand Solid Reboreable, 1/2 to 11/16 in Bore, 1.746 in OD, #35 Chain, 13 Teeth, 3/8 in Pitch, 1.567 in Pitch Diameter, 1.109 in Diameter Hub, 1-3/4 in Length Through Bore, Steel
SPECIFICATIONS
| Bore Diameter | : | 1/2 to 11/16 in |
| Outside Diameter | : | 1.746 in |
| Chain Size | : | #35 |
| Number of Teeth | : | 13 |
| Pitch | : | 3/8 in |
| Material | : | Steel |
| Hub Diameter | : | 1.109 in |
| Type | : | Type B Triple Strand Solid Reboreable |
| Length Through Bore | : | 1-3/4 in |
| Pitch Diameter | : | 1.567 in |
DOCUMENTS
-
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Martin_815A13B_Specification_Sheet.pdf -
VIDEO LINK
https://www.youtube.com/watch?v=fSomOMNB_-Q
