- Martin DS50ATB21H
DS50ATB21H
Martin DS50ATB21H Type A Double Single Strand Bushed Roller Chain Sprocket With Hardened Teeth, 1/2 to 2 in Dia Bore, 4.522 in OD, #50 Chain, 21 Teeth, 5/8 in Pitch, Steel
- CP#:
- Item#: DS50ATB21H
- Mfr#: DS50ATB21H
- UPC: 697950029733
- To be run with two separate single row chains
- Precise machining and processes ensure consistent finish and high quality
- Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
- Bores are concentric to pitch line, minimizing run out
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Double single sprockets are precision machined steel sprockets and run with two single chains. They are stocked in minimum plain bore, taper bushed and Martin split taper style. The minimum plain bores can be quickly modified for your specific application.
Martin Roller Chain Sprocket, Type A Double Single Strand Bushed, 1/2 to 2 in Bore, 4.522 in OD, #50 Chain, 21 Teeth, 5/8 in Pitch, 4.1934 in Pitch Diameter, 3.484 in Diameter Hub, 1.656 in Length Through Bore, TB 2012 Bushing, Steel
SPECIFICATIONS
| Bushing Type | : | TB 2012 |
| Bore Diameter | : | 1/2 to 2 in |
| Outside Diameter | : | 4.522 in |
| Chain Size | : | #50 |
| Number of Teeth | : | 21 |
| Pitch | : | 5/8 in |
| Material | : | Steel |
| Length Through Bore | : | 1.656 in |
| Pitch Diameter | : | 4.1934 in |
| Type | : | Type A Double Single Strand Bushed |
| Hub Diameter | : | 3.484 in |
DOCUMENTS
-
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Martin_815A13B_Specification_Sheet.pdf -
VIDEO LINK
https://www.youtube.com/watch?v=fSomOMNB_-Q
