D60E60
Martin D60E60 Double Strand QD Bushed Solid Type C2 Single Roller Chain Sprocket, 14.761 in OD, 60-2 Chain, 60 Teeth, 3/4 in Pitch, Steel
- CP#:
- Item#: D60E60
- Mfr#: D60E60
- UPC: 697950018829
- Manufactured of high carbon steel
- Precise machining and processes ensure consistent finish and high quality
- Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
QD (quick detachable)is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip.
Martin Single Roller Chain Sprocket, Double Strand QD Bushed Solid Type C2, 14.761 in Outside Dia, 60-2 Chain, 60 Teeth, 3/4 in Pitch, 14.331 in, 6 in Hub Dia, 2-5/8 in Length Through Bore, Type E QD® Bushing, Steel
SPECIFICATIONS
| Bushing Type | : | Type E QD® |
| Outside Diameter | : | 14.761 in |
| Chain Size | : | 60-2 |
| Number of Teeth | : | 60 |
| Pitch | : | 3/4 in |
| Material | : | Steel |
| Length Through Bore | : | 2-5/8 in |
| Pitch Diameter | : | 14.331 in |
| Type | : | Double Strand QD Bushed Solid Type C2 |
| Hub Diameter | : | 6 in |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Martin_50A112_Catalog.pdf
