C6-RRDSA4-60
Martin C6-RRDSA4-60 Self Aligner Rubber Disc Return Idler, C CEMA Rating, 6 in Dia Roll, 60 in W Belt
- CP#:
- Item#: C6-RRDSA4-60
- Mfr#: C6-RRDSA4-60
- UPC: 697950855622
- Manufactured using sealed for life ball bearings for long maintenance-free operation
- Martin premium triple labyrinth seal guard bearing protection
- Protected roll weld
- Martin triple labyrinth seal guard offers a balance of seal performance and low rolling resistance
- External shield deters impurities from entering the bearing housing
- Flinger design removes contaminates away from the bearing housing by centrifugal force
- Grease is injected into the labyrinth chambers during manufacturing to add an additional layer of protection against bearing contamination
- The contact lip seal adds an additional level of protection against moisture and fine particulate contaminants
- CEMA C idlers have sealed for life ball bearings
- Martin CEMA C idlers offer low rolling resistance that allows for lower operating cost
- Recessed and protected bearing housing weld protects against wear from belt
- Oversized, solid steel shaft machined to 20 mm for bearings
- Martin idlers have low TIR
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Rubber disc returns are used to support the belt on the return side when the conveyed material is sticky or abrasive. The spaced rubber discs flex and offer relief to avoid material build up caused by excessive carryback. Rolls have flat, massed rubber ends to offer support if the belt mistracks from center.
Martin Rubber Disc Return Idler, Self Aligner, C CEMA, 6 in Roll Diameter, 60 in Belt Width, Sealed Ball Bearing, 63.13 in Roller Length, 72-1/2 in Overall Width, 69 in Distance Between Mounting Holes
SPECIFICATIONS
| Roller Length | : | 63.13 in |
| Belt Width | : | 60 in |
| Type | : | Self Aligner |
| Distance Between Mounting Holes | : | 69 in |
| Overall Width | : | 72-1/2 in |
| Bearing Type | : | Sealed Ball |
| CEMA Rating | : | C |
| Roll Diameter | : | 6 in |
