60SDS19H
Martin 60SDS19H Type B Single Strand Solid Bushed Roller Chain Sprocket With Hardened Teeth, 1/2 to 2 in Dia Bore, 4.945 in OD, #60 Chain, 19 Teeth, 3/4 in Pitch, Steel
- CP#:
- Item#: 60SDS19H
- Mfr#: 60SDS19H
- UPC: 697950041995
- Interchangeable with other manufacturer's QD® bushings
- Stocked heat treat
- Precise machining and processes ensure consistent finish and high quality
- Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
- Bores are concentric to pitch line, minimizing run out
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Martin saber tooth sprockets have hardened teeth, which provide longer chain and sprocket life. The hardened teeth on the smaller sprocket of a roller chain drive are recommended if the drive ratio is four to one or greater if the smaller sprocket has 24 teeth or less and is running at a speed of over 600 rpm.
Martin Roller Chain Sprocket, Type B Single Strand Solid Bushed, 1/2 to 2 in Bore, 4.945 in OD, #60 Chain, 19 Teeth, 3/4 in Pitch, 4.5567 in Pitch Diameter, 3-3/16 in Diameter Hub, 1/4-20 UNC Screw, 3/4 in Length Through Bore, QD® SDS Bushing, Steel
SPECIFICATIONS
| Bushing Type | : | QD® SDS |
| Bore Diameter | : | 1/2 to 2 in |
| Outside Diameter | : | 4.945 in |
| Chain Size | : | #60 |
| Number of Teeth | : | 19 |
| Pitch | : | 3/4 in |
| Material | : | Steel |
| Type | : | Type B Single Strand Solid Bushed |
| Pitch Diameter | : | 4.5567 in |
| Hub Diameter | : | 3-3/16 in |
| Length Through Bore | : | 3/4 in |
| Screw Size | : | 1/4-20 UNC |
DOCUMENTS
-
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Martin_815A13B_Specification_Sheet.pdf -
VIDEO LINK
https://www.youtube.com/watch?v=fSomOMNB_-Q
